41.52.9.012.0010
DPDT PCB Mount Non-Latching Relay Through Hole, 12V dc | Finder 41.52.9.012.0010
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 41.52.9.012.0010 by Finder and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 41.52.9.012.0010
| Part Name | 41.52.9.012.0010 |
| Manufacturer | Finder |
| Category | Relays |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Mounting Type | PCB Mount |
| Terminal Type | Through Hole |
| Coil Power | 400 (mW) |
| Series | 41 Series |
| Latching | No |
| Coil Voltage (V) | 12 (V dc) |
| Number Of Poles | 2 |
| Length | 29 (mm) |
| Contact Configuration | DPDT |
| Coil Resistance | 360 (Ω) |
| Application | Power |
| Depth | 12.5 (mm) |
| Minimum Operating Temperature | -40 (°C) |
| Distrelec Product Id | 13744378 |
| Maximum Switching Power Ac | 2 kVA |
| Height | 15.7 (mm) |
| Maximum Operating Temperature | +85 (°C) |
| Switching Current (A) | 8 (A) |
| Contact Material | Silver Alloy |
