5-104505-7
Crimp Pin Connector, Gold / Nickel Plating 26-22 AWG, AMPMODU MTE Series | TE Connectivity 5-104505-7
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5-104505-7 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5-104505-7
| Part Name | 5-104505-7 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Dielectric Withstanding Voltage (V) | 750 |
| Insulation Resistance | 5000 |
| Crimp Area Plating Thickness | 50 – 100 |
| Operating Voltage (V) | 300 |
| Wire Contact Termination Area Plating Material | Tin |
| Contact Current Rating (Max) (A) | 3 |
| TE Internal Number | 5-104505-7 |
| Termination Method to Wire & Cable | Insulation Displacement Crimp (IDC) |
| Termination Resistance | 12 |
| Product Type | Contact |
| Wire Insulation Support | With |
| Contact Transmits (Typical) | Signal (Data)/Power |
| Operating Temperature Range | -65 – 105 |
| Insulation Diameter | .91 – 1.37 |
| Packaging Method | Loose Piece |
| Packaging Quantity | 500 |
| Applied Pressure | Standard |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Approved Standards | UL E28476 |
| Contact Base Material | Phosphor Bronze |
| Crimp Area Plating Material Finish | Matte |
| Contact Mating Area Plating Thickness | 30 |
| Contact Type | Pin |
| PCB Contact Termination Area Plating Material | Tin |
| Wire Size | .12 – .4 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Minimum Wire Size Mm | 0.1 (mm²) |
| Maximum Wire Size Mm | 0.4 (mm²) |
| Minimum Operating Temperature | -65 (°C) |
| Maximum Contact Resistance | 12 mΩ |
| Series | AMPMODU MTE |
| Minimum Wire Size Awg | 26 (AWG) |
| Gender | Male |
| Contact Plating | Gold |
| Termination Method | Crimp |
| For Use With | AMPMODU MTE Connector Housing |
| Maximum Wire Size Awg | 22 (AWG) |
| Maximum Operating Temperature | +105 (°C) |
| Contact Material | Phosphor Bronze |
Inventory for the 5-104505-7 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
16,808
|
|
Visit Site | |
|
★ Featured
|
4,064
|
|
Visit Site | |
| Arrow Electronics |
41,006
|
|
Visit Site | |
| Onlinecomponents |
21,831
|
|
Visit Site | |
| Verical |
1,500
|
|
Visit Site |
No issues have been reported for the 5-104505-7
