504050-0691
1.5mm Pitch, Pico Lock PCB Header, Single Row, Right Angle, Gold, 6 Circuits | Molex Incorporated 504050-0691
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 504050-0691 by Molex and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 504050-0691
| Part Name | 504050-0691 |
| Manufacturer | Molex |
| Category | Connectors |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Shrouded/Unshrouded | Shrouded |
| Current Rating (A) | 3.0 (A) |
| Mounting Type | Surface Mount |
| Voltage Rating (V) | 150.0 V |
| Series | Pico-Lock |
| Body Orientation | Right Angle |
| Pitch | 1.5 (mm) |
| Connector System | Wire to Board |
| Number Of Rows | 1 |
| Contact Plating | Gold |
| Termination Method | Solder |
| Contact Material | Copper Alloy |
| Number Of Contacts | 6 |
| Series Number | 504050 |
Inventory for the 504050-0691 by Molex from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
25,310
|
|
Visit Site | |
|
★ Featured
|
13,627
|
|
Visit Site | |
|
★ Featured
|
51,875
|
1,735 x $0.17
|
Visit Site | |
| Avnet America |
18,900
|
|
Visit Site | |
| Conrad |
2,593
|
1 x $0.88
|
Visit Site | |
| CoreStaff |
15,945
|
|
Visit Site | |
| Farnell UK |
5,400
|
|
Visit Site | |
| Heilind Americas |
1,875
|
|
Visit Site | |
| Newark |
5,400
|
|
Visit Site | |
| Onlinecomponents |
202,169
|
|
Visit Site | |
| Powell Electronics |
146,811
|
|
Visit Site | |
| RS Americas |
2,499
|
1 x $0.61
|
Visit Site | |
| Rutronik |
|
32,400 x $1.04
|
Visit Site | |
| TME |
1,067
|
|
Visit Site | |
| TTI Americas |
8,100
|
2,700 x $0.71
|
Visit Site | |
| Verical |
15,945
|
55 x $1.28
|
Visit Site | |
| element14 Singapore |
5,400
|
|
Visit Site |
No issues have been reported for the 504050-0691
