5120534-1
SnapVerified
Male Backplane Connector SMT, 64 Way, 1mm Pitch, 1A | TE Connectivity 5120534-1
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5120534-1 by TE Connectivity / AMP and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5120534-1
| Part Name | 5120534-1 |
| Manufacturer | TE Connectivity / AMP |
| Category | Connectors |
| Mating Alignment Type | None |
| Contact Current Rating (Max) (A) | 1 |
| Centerline (Pitch) | .039 |
| Agency/Standard | CSA |
| Circuit Application | Signal |
| Contact Underplating Material Thickness | 50 |
| Stack Height | 13 |
| Mating Retention | Without |
| Insulation Resistance | 2 |
| Operating Voltage (V) | 250 |
| PCB Mount Alignment Type | Locating Posts |
| UL Rating | Listed |
| Number of Positions | 64 |
| PCB Mount Retention Type | None |
| PCB Mount Retention | Without |
| Housing Material | Thermoplastic |
| PCB Connector Assembly Type | PCB Mount Header |
| Mating Post Length | .168 |
| TE Internal Number | 5120534-1 |
| PCB Mount Orientation | Vertical |
| Connector System | Board-to-Board |
| Connector Height | .329 |
| Number of Rows | 2 |
| Housing Color | Black |
| Connector Width | 150 |
| Contact Base Material | Phosphor Bronze |
| PCB Contact Termination Area Plating Material Thickness | 3.81 |
| Industry Standard | IEEE 1386 |
| Number of Columns | 32 |
| Connector Length | 34.22 |
| UL File Number | E28476 |
| Assembly Process Feature | Pick and Place Cover |
| Operating Temperature Range | -67 – 230 |
| CSA Certified | Yes |
| Mating Entry Location | Top |
| Packaging Method | Tape & Reel |
| Packaging Quantity | 400 |
| Contact Configuration | Single Beam |
| Contact Layout | Inline |
| Connector & Contact Terminates To | Printed Circuit Board |
| Differential Signaling | Yes |
| Mating Alignment | Without |
| Contact Mating Area Plating Material | Gold |
| Stackable | Yes |
| Termination Method to Printed Circuit Board | Surface Mount |
| Board-to-Board Configuration | Mezzanine |
| PCB Mount Alignment | Without |
| UL Flammability Rating | UL 94V-0 |
| Contact Mating Area Plating Material Thickness | .76 |
| PCB マウント アラインメント タイプ | Locating Posts |
| CSA File Number | LR7189 |
| PCB Contact Termination Area Plating Material Finish | Matte |
| Contact Type | Pin |
| PCB Contact Termination Area Plating Material | Tin |
| Sealable | No |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
