5145263-3
Conn Card Edge SKT 124 POS 1mm Solder ST Thru-Hole Bag
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5145263-3 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5145263-3
| Part Name | 5145263-3 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarization |
| Centerline (Pitch) | .039 |
| Circuit Application | Signal |
| Housing Material | Thermoplastic |
| Contact Termination Area Plating Thickness | 2.54 |
| Operating Voltage (V) | 60 |
| For Use With | Printed Circuit Board |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention Type | Boardlock |
| PCB Mount Retention | With |
| Termination Post & Tail Length | .125 |
| Operating Temperature Range | -67 – 185 |
| TE Internal Number | 5145263-3 |
| PCB Mount Orientation | Vertical |
| Connector System | Board-to-Board |
| Number of Rows | 2 |
| Housing Color | Brown |
| Bus Type | AGP (Accelerated Graphic Port) |
| Number of Dual Positions | 0 |
| Contact Base Material | Phosphor Bronze |
| Connector Mounting Type | Board Mount |
| Hold-Down Plating Material | Tin over Nickel |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Anzahl der Einzelpositionen | 62 |
| Hold-Down Length | 4.38 |
| Packaging Method | Bag |
| Housing Type | Receptacle |
| Packaging Quantity | 48 |
| Number of Signal Positions | 124 |
| Contact Termination Area Plating Material | Tin over Nickel |
| Number of Positions | 124 |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold |
| Mating Retention | Without |
| Product Type | Connector Assembly |
| PCB Mount Alignment | Without |
| Height | 13.97 |
| Contact Current Rating (Max) (A) | 124 |
| Contact Mating Area Plating Thickness | .38 |
| End Caps | Without |
| Contact Type | Socket |
