5145299-1
SnapVerified
Conn, Rect,Board to Board,6 (Signal), 2 (Switch) Cont,Solder,2.54mm Pin-Spng | TE Connectivity 5145299-1
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5145299-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5145299-1
| Part Name | 5145299-1 |
| Manufacturer | TE Connectivity |
| Category | Connectors |
| Durability Rating | 10000 |
| Centerline (Pitch) | 2.54 |
| Card Type | SIM/SAM |
| Circuit Application | Signal |
| Switch Style | Unsealed |
| Housing Material | High Temperature Thermoplastic |
| Number of Positions | 6 |
| Profile | Standard |
| Accepts Card Thickness | .03 |
| TE Internal Number | 5145299-1 |
| Connector & Contact Terminates To | Printed Circuit Board |
| Housing Color | Black |
| Contact Underplating Material | Nickel |
| Number of Signal Positions | 6 |
| Strain Relief | Without |
| Connector Mounting Type | Board Mount |
| Cable | Without |
| Operating Temperature Range | -40 – 90 |
| Contact Base Material | Phosphor Bronze |
| Cover | With |
| Packaging Method | Carton |
| Packaging Quantity | 500 |
| Cable Mounting Style | Non Cable |
| Card Detection Switch | With |
| Card Detection Switch Position | No |
| Height Above PC Board | 4.05 |
| Contact Mating Area Plating Material | Gold |
| Card Guide Slots | With |
| RoHS | True |
| PCB Mounting Style | Surface Mount |
| 端子の下地めっきの材料 | Nickel |
| Number of Switch Contacts | 2 |
| Cable Type | Non Cable |
| Contact Current Rating (Max) (A) | .2 |
| Card Scoop | With |
| Product Type | Connector |
| Termination Type | IDC |
| PCB Contact Termination Area Plating Material | Tin |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Dimensions | 20 x 4.05 x 29.9 (mm) |
| Mounting Type | Surface Mount |
| Card Type | SAM, SIM |
| Gender | Male |
| Body Orientation | Straight |
| Pitch | 2.54 (mm) |
| Depth | 29.9 (mm) |
| Housing Material | Thermoplastic |
| Width | 4.05 (mm) |
| Length | 20.0 (mm) |
| Number Of Rows | 2 |
| Contact Plating | Gold over Nickel |
| Termination Method | Solder |
| Number Of Contacts | 6 |
| Contact Material | Phosphor Bronze |
