5205732-1
HD20/22 Series 50/78 Position Thermoplastic 180°/45° Exit Angle Cable Clamp Kit
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5205732-1 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5205732-1
| Part Name | 5205732-1 |
| Manufacturer | TE Connectivity / AMP |
| Cable Insulation Diameter | 15.24 |
| Shield Plating Material | None |
| Cable Clamp Material | Polypropylene |
| Shielded | No |
| Farbe | Black |
| Clam Shell Length | Standard |
| Screw & Hole Thread Size | 6-32 |
| Packaging Method | Bag |
| TE Internal Number | 5205732-1 |
| Accessory Type | Cable Clamp |
| Cable Exit Angle | 180 |
| Grommets | Without |
| Shell Size | 5 |
| For Use With | Plug/Receptacle |
| Cable Clamp Type | Clam Shell |
| Product Type | Accessory |
| Connector & Contact Terminates To | Wire & Cable |
| RoHS | True |
| Screws and Retainer Clips | Without |
