530733-8
MINI BX PIN HDR ASY 110 POS RA
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 530733-8 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 530733-8
| Part Name | 530733-8 |
| Manufacturer | TE Connectivity |
| Mating Alignment Type | Polarized |
| Centerline (Pitch) | .05 |
| Housing Material | LCP (Liquid Crystal Polymer) |
| Connector & Contact Terminates To | Printed Circuit Board |
| Number of Positions | 110 |
| PCB Mount Retention | Without |
| Termination Post & Tail Length | .185 |
| TE Internal Number | 530733-8 |
| PCB Mount Orientation | Right Angle |
| Connector Height | 13.21 |
| Number of Rows | 2 |
| Housing Color | Gray |
| Sealable | No |
| Assembly Process Feature | None |
| Packaging Method | Package |
| Packaging Quantity | 6 |
| Stackable | No |
| Contact Layout | Staggered |
| Mating Alignment | With |
| Contact Mating Area Plating Material | Gold |
| RoHS | True |
| Life Cycle Status | Restricted Availability |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Contact Base Material | Brass |
| Post Size | .23 x .46 |
| Contact Mating Area Plating Material Thickness | 30 |
| Row-to-Row Spacing | .15 |
| PCB Connector Assembly Type | PCB Mount Header |
| PCB Contact Termination Area Plating Material Finish | Matte |
| Contact Type | Pin |
| PCB Contact Termination Area Plating Material | Tin-Lead |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 530733-8 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| Conrad |
84
|
1 x $193.81
|
Visit Site | |
| Farnell UK |
77
|
|
Visit Site | |
| Mouser |
|
N/A | Visit Site | |
| Newark |
84
|
1 x $164.18
|
Visit Site | |
| Onlinecomponents |
79
|
|
Visit Site | |
| Powell Electronics |
55
|
|
Visit Site | |
| TME |
5
|
|
Visit Site | |
| TTI Americas |
|
6 x $234.76
|
Visit Site | |
| Verical |
7
|
|
Visit Site |
No issues have been reported for the 530733-8
If you experienced any issues with this part, please report it.
