5353928-2
SnapVerified
USB-A (USB TYPE-A) USB 2.0 Receptacle Connector 4 Position Panel Mount, Surface Mount, Right Angle
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 5353928-2 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 5353928-2
| Part Name | 5353928-2 |
| Manufacturer | TE Connectivity |
| Pick & Place Capable | Yes |
| Shell Plating Material | Tin |
| Centerline (Pitch) | 2 |
| USB Version | 2.0 |
| Circuit Application | Power & Signal |
| USB Type | A |
| Number of Mounting Legs | 2 |
| Housing Material | Thermoplastic |
| Ground Component Type | M2 Threaded Hole |
| Contact Termination Type | Surface Mount |
| PCB Connector Seating | Offset |
| Connector Style | Receptacle |
| Number of Positions | 4 |
| PCB Mount Retention Type | SMT Hold-Down |
| Locking Feature | With |
| PCB Thickness (Recommended) | .039 |
| Operating Temperature Range | -67 – 185 |
| TE Internal Number | 5353928-2 |
| Connector & Contact Terminates To | Printed Circuit Board |
| Connector System | Cable-to-Panel |
| Contact Mating Area Plating Thickness | .76 |
| Housing Color | Black |
| Offset | 4 |
| Product Type | Connector |
| Connector Mounting Type | Panel |
| Moisture Sensitivity Level | 1 |
| Industry Standard | USB 2.0 |
| Mounting Location | Top |
| Shell Plating Finish | Bright |
| Locating Posts | With |
| Pick and Place | Pick and Place Cover |
| Packaging Method | Tape & Reel |
| Termination Method | Solder |
| Packaging Quantity | 350 |
| Tail Length | .073 |
| Number of Ports | 1 |
| Halogen Free | No |
| Contact Mating Area Plating Material | Gold or Gold Flash over Palladium Nickel |
| Panel Mount Feature Type | Flange |
| Soldering Temperature (Max) | 500 |
| RoHS | True |
| Termination Method to Printed Circuit Board | Reflow Solder |
| LED | Without |
| Orientation | Right Angle |
| Panel Ground Location | Right/Left |
| Grounding Options | Panel Ground |
| Contact Current Rating (Max) (A) | 1 |
| Mating Cycles (Max) | 1500 |
| UL Flammability Rating | UL 94V-0 |
| Size | Standard |
