543633P064
SCT-NO.1-E6-0-STK | TE Connectivity 543633P064
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 543633P064 by TE Connectivity / Raychem and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 543633P064
| Part Name | 543633P064 |
| Manufacturer | TE Connectivity / Raychem |
| Category | Wire & Cable |
| Shrink Temperature (Min) | 125 |
| Expanded Inside Diameter (Min) | 7.62 |
| Product Source | US |
| Flammability | Flame-Retardant |
| Wall Type | Dual |
| Material | Irradiated Modified Polyolefin |
| TE Internal Number | 543633P064 |
| Voltage (Max) (V) | .6 |
| Cut Length | 1220 – 1245.4 |
| Recovery Temperature | 135 |
| Operating Temperature Range | -40 – 150 |
| Fluid Type | Diesel Fuel |
| Packaging Method | Stick |
| Fluid Resistance | Moisture/Spray Protection |
| Recovered Wall Thickness (Tolerance) | .06 |
| Resistant To | Vibration |
| Product Family | SCT |
| Color | Black |
| Recovered Inside Diameter (Max) | 1.65 |
| Applicable Region | Global |
| Flexibility | Semi-Rigid |
| Shrink Ratio | 4:1 |
| Low Outgassing | No |
