626056
Multiple Circuit Housings with Tabs & Receptacles Including FASTIN-FASTON
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 626056 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 626056
| Part Name | 626056 |
| Manufacturer | TE Connectivity |
| Mating Retention | With |
| Insulated | No |
| Product Type | Terminal Housing |
| Operating Temperature Range | -40 – 105 |
| Terminal & Splice Type | Receptacle |
| Sealable | No |
| Packaging Method | Bag/Carton |
| Mating Retention Type | Latch |
| Packaging Quantity | 10000 |
| TE Internal Number | 626056 |
| Housing Material | Polyamide |
| Terminal Orientation | Straight |
| Housing Type | Receptacle Housing |
| Length | .708 |
| Mating Alignment | With |
| Mounting Style | Free Hanging |
| Centerline | .196 |
| Number of Positions | 4 |
| Housing Color | Natural |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Tab Width | 6.35 (mm) |
| Series | AMP FASTIN-FASTON |
| Colour | Natural |
| Length | 22.9 (mm) |
| Connector Type | Plug |
| Body Material | Nylon 66 |
| Number Of Contacts | 4 |
