66584-4
Socket Contact Gold Crimp 20-24 AWG Stamped
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 66584-4 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 66584-4
| Part Name | 66584-4 |
| Manufacturer | TE Connectivity |
| Product Type | Contact |
| Circuit Application | Signal |
| Packaging Method | Reel |
| TE Internal Number | 66584-4 |
| Packaging Quantity | 5000 |
| Contact Base Material | Brass |
| For Use With | G Series Connectors |
| Contact Termination Area Plating Material | Tin |
| Contact Mating Area Plating Thickness | 30 |
| Wire/Cable Type | Discrete Wire |
| Termination Type | Crimp |
| Contact Mating Area Plating Material | Gold |
| Contact Type | Socket |
| Accepts Wire Insulation Diameter Range | .04 – .08 |
| Contact Size | 16 |
| Wire Size | 24 – 20 |
| Connector & Contact Terminates To | Wire & Cable |
| RoHS | N |
| Test Current (A) | 13 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
