74HC27D,652
NOR Gate IC 3 Channel - 14-SO
Availability: Out of Stock
Package Type: SO14-14
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 74HC27D,652 by Nexperia and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 74HC27D,652
| Part Name | 74HC27D,652 |
| Manufacturer | Nexperia |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Pin Count | 14 |
| Maximum Low Level Output Current (A) | 5.2 (mA) |
| Number Of Elements | 3 |
| Dimensions | 8.75 x 4 x 1.45 (mm) |
| Maximum Operating Supply Voltage (V) | 6 V |
| Number Of Inputs Per Gate | 3 |
| Mounting Type | Surface Mount |
| Maximum Propagation Delay Time Maximum Cl | 135 (ns) |
| Logic Function | NOR |
| Logic Family | HC |
| Height | 1.45 (mm) |
| Width | 4 (mm) |
| Length | 8.75 (mm) |
| Package Type | SOIC |
| Input Type | CMOS |
| Schmitt Trigger Input | No |
| Minimum Operating Supply Voltage (V) | 2 V |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Temperature | -40 °C |
| Propagation Delay Test Condition | 50 (pF) |
| Maximum High Level Output Current (A) | -5.2 (mA) |
No issues have been reported for the 74HC27D,652
If you experienced any issues with the symbol or footprint, please report it.
