XTAL, 12.288MHZ, 18PF, SMD, 5.0X3.2; Frequency:12.288MHz; Frequency Tolerance:± 30ppm; Load Capacitance:18pF; Frequency Stability:± 30ppm; Operating Temperature Range:-20°C to +70°C; Crystal Mounting Type:SMD; Crystal Case Type:5mm x 3.2mm; No. of Pins:2; SVHC:No SVHC (19-Dec-2011); Series:7A
Availability: Out of Stock
Package Type: SMD-2
CAD Models: Footprint
No web preview
This Footprint is Available for
Specifications for the 7A-12.288MAAJ-T
|Formats Available for
Symbols and Footprints
|Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus|
We could not find inventory or pricing across major distributors for the 7A-12.288MAAJ-T by TXC CORPORATION.
