828296-8
SnapVerified
16 Position Header Spacer Connector 0.100" (2.54mm) Gold Through Hole
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 828296-8 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 828296-8
| Part Name | 828296-8 |
| Manufacturer | TE Connectivity |
| Centerline (Pitch) | 2.54 |
| Dielectric Withstanding Voltage (V) | 750 V |
| Termination Method to Printed Circuit Board | Through Hole - Solder |
| Row-to-Row Spacing | .1 |
| Insulation Resistance | 5000 |
| Connector & Contact Terminates To | Printed Circuit Board |
| PCB Mount Retention | Without |
| Termination Post & Tail Length | 3.2 |
| Contact Current Rating (Max) (A) | 5 |
| Mating Post Length | 4.4 |
| TE Internal Number | 828296-8 |
| PCB Mount Orientation | Vertical |
| Number of Rows | 2 |
| Housing Color | Green |
| Header Type | Breakaway |
| Contact Underplating Material | Nickel |
| Contact Base Material | CuZn |
| Contact Shape | Square |
| PCB Contact Termination Area Plating Material Thickness | 3 – 5 |
| Operating Temperature Range | -65 – 105 |
| Packaging Method | Box |
| Packaging Quantity | 100 |
| Contact Type | Pin |
| Number of Positions | 16 |
| Mating Alignment | Without |
| Contact Mating Area Plating Material | Gold Flash |
| RoHS | True |
| Housing Material | PBT |
| 端子の下地めっきの材料 | Nickel |
| High Temperature Housing | No |
| Post Size | .0248 |
| Panel Mount Feature | Without |
| PCB Connector Assembly Type | PCB Mount Header |
| Connector Contact Load Condition | Fully Loaded |
| Connector Profile | Standard |
| Solder Process Feature | Board Standoff |
| PCB Contact Termination Area Plating Material | Tin |
| Position Locations Omitted | None |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 828296-8 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
652
|
35 x $2.11
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Boersig GmbH |
|
1 x $2.07
|
Visit Site | |
| Buerklin |
92
|
|
Visit Site | |
| Chip One Stop |
652
|
|
Visit Site | |
| Conrad |
826
|
1 x $1.74
|
Visit Site | |
| Farnell UK |
744
|
|
Visit Site | |
| Heilind Americas |
|
|
Visit Site | |
| Interstate Connecting Components |
|
|
Visit Site | |
| Newark |
652
|
1 x $2.32
|
Visit Site | |
| Onlinecomponents |
652
|
|
Visit Site | |
| Powell Electronics |
430
|
|
Visit Site | |
| Sager |
|
100 x $2.31
|
Visit Site | |
| TME |
652
|
|
Visit Site | |
| Verical |
652
|
|
Visit Site |
No issues have been reported for the 828296-8
If you experienced any issues with the symbol or footprint, please report it.
