880584-4
2 (1 x 2) Position Shunt Connector Black Closed Top, Grip 0.100" (2.54mm) Tin
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the 880584-4 by TE Connectivity and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the 880584-4
| Part Name | 880584-4 |
| Manufacturer | TE Connectivity |
| Profile | Low |
| Contact Base Material | Phosphor Bronze |
| Handle | With |
| Operating Temperature Range | -40 – 85 |
| Shunt Style | Closed Top |
| Termination Resistance | 15 |
| Packaging Method | Loose Piece |
| TE Internal Number | 880584-4 |
| Packaging Quantity | 14000 |
| UL Flammability Rating | UL 94V-0 |
| Housing Material | Thermoplastic |
| Contact Current Rating (Max) (A) | 3 |
| Shunt Type | Novo |
| Insulation Resistance | 5000 |
| Housing Color | Black |
| Contact Mating Area Plating Material | Tin |
| Centerline (Pitch) | 2.54 |
| Height | .551 |
| Number of Positions | 2 |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
Inventory for the 880584-4 by TE Connectivity from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| TE Connectivity |
23,199
|
|
Visit Site |
No issues have been reported for the 880584-4
