AD625KNZ
Programmable Gain Instrumentation Amplifier
Availability: Out of Stock
Package Type: PDIP-16
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the AD625KNZ by Analog Devices and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the AD625KNZ
| Part Name | AD625KNZ |
| Manufacturer | Analog Devices |
| Product Category | Instrumentation Amplifiers |
| Package | PLASTIC DIP |
| MOQ | 1 |
| RoHS value | Yes |
| Part Launch Date | 6/30/2005 4:53:20 AM |
| Temperature Range | 0 to 70C |
| Product Link | https://www.analog.com/en/products/ad625.html?ADICID=SYND_WW_P682800_PF-snapeda |
| Pins | 16 |
| Product Lifecycle | Production |
| RoHS | Yes |
| Life Cycle Status | Restricted Availability |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | |
| Minimum Cmrr | 75 (dB) |
| Maximum Input Offset Voltage (V) | 0.025 (mV) |
| Typical Dual Supply Voltage (V) | ±12 V, ±15 V, ±9 V |
| Dimensions | 19.18 x 6.61 x 3.56 (mm) |
| Mounting Type | Through Hole |
| Maximum Input Resistance | 1 (GΩ) |
| Power Supply Type | Dual |
| Typical Gain Bandwidth Product | 25 (MHz) |
| Height | 3.56 (mm) |
| Width | 6.61 (mm) |
| Length | 19.18 (mm) |
| Package Type | PDIP |
| Minimum Operating Temperature | 0 °C |
| Rail To Rail | No |
| Maximum Operating Temperature | +70 °C |
| Pin Count | 16 |
No issues have been reported for the AD625KNZ
If you experienced any issues with the symbol or footprint, please report it.
