ARRAN5-868.000MHZ
868MHZ RFID READER ANT MMCX-JW3
Availability: Out of Stock
Package Type: MODULE
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the ARRAN5-868.000MHZ by Abracon and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
Verification | Issues | Specs |
Specifications for the ARRAN5-868.000MHZ
Part Name | ARRAN5-868.000MHZ |
Manufacturer | Abracon |
Frequency Range | 868 ±3MHz |
Gain Display | 0.5 |
Mounting | Connector Mount |
Polarization | RHCP |
Width | 35 |
Length | 35 |
ESD | No |
Bandwidth Max | 2.5 |
Bandwidth Min | 2.5 |
Height | 8.2 |
Type | Internal/Embedded |
RoHS | Yes |
Frequency Group | UHF (300MHz ~ 1GHz) |
Protocol | LPWA, LoRA/SigFox, ISM, RFID, UHF |
Frequency Maximum | 868 |
Frequency Minimum | 868 |
Sub-type | Passive Patch |
Bandwidth Range | 2.5 |
Pb Free | No |
Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
Datasheet | See Datasheet PDF |
No issues have been reported for the ARRAN5-868.000MHZ
If you experienced any issues with this part, please report it.
