AS01808AO-3-R
18X13MM SPEAKER 420HZ 94DB 8OHM 1W ALUMINUM
Availability: Out of Stock
Package Type: CUSTOM
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the AS01808AO-3-R by PUI Audio and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Design & more
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the AS01808AO-3-R
| Part Name | AS01808AO-3-R |
| Manufacturer | PUI Audio |
| SPL at 10 cm | 94.0 |
| Freq min in Khz | 0.42 |
| Impedance in ohms | 8.0 |
| Device Type | Speaker |
| Rated Input Power | 1.0 |
| Magnet Material | NdFeB |
| Lead Time | 125 |
| Resonant Frequency Khz | 0.42 |
| MULT | 50 |
| Status | Active |
| SPQ | 50 |
| Weight in grams | 2.0 |
| Tolerance percentage | 15.0 |
| REACH | Yes |
| SPU | TRAY |
| RoHS | Yes |
| Freq max in Khz | 14.0 |
| Country Code | CN |
| Diaphragm Material | Aluminum |
| Tolerance - dB | 3 |
| Operating Temp. | -25 to 60 |
| Temp. Grade | Standard |
| HTS Code | 8518.29.8000 |
| MOQ | 50 |
| Input Power Max | 1.2 |
| Dimmensions in mm. | 18 x 13 x 2.5 |
| Product Link | https://www.puiaudio.com/products/as01808ao-3-r |
| Shape | Oval |
