AUIRFR6215TRL
Advanced planar technology | Dynamic dV/dT rating | 175C operating temperature | Fast switching | Fully Avalanche Rated | Repetitive avalanche allowed up to Tjmax | Lead free, RoHS compliant | Automotive qualified
Availability: In Stock
Package Type: TO-252
CAD Models: Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the AUIRFR6215TRL by Infineon and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
The 2D model for this
part is not available.
The Exact Symbol for this part is not available.
Build
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the AUIRFR6215TRL
| Part Name | AUIRFR6215TRL |
| Manufacturer | Infineon |
| Product Link | https://www.infineon.com/cms/en/product/power/mosfet/20v-800v-automotive-mosfet/20v-150v-p-channel-automotive-mosfet/auirfr6215/ |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Drain Source Voltage (V) | 150 V |
| Channel Mode | Enhancement |
| Maximum Continuous Drain Current (A) | 13 A |
| Series | HEXFET |
| Channel Type | P |
| Maximum Gate Threshold Voltage (V) | 4 (V) |
| Maximum Drain Source Resistance | 0.295 Ω |
| Package Type | DPAK (TO-252) |
| Number Of Elements Per Chip | 1 |
| Mounting Type | Surface Mount |
| Transistor Material | Silicon |
| Pin Count | 3 |
