B72500E0200K060
VARISTOR, MULTILAYER, 26VDC, 0603; Series:MLV E; Varistor Type:Multilayer Varistor (MLV); Peak Surge Current @ 8/20µs:30A; Varistor Case:0603 [1608 Metric]; Clamping Voltage Vc Max:56V; Voltage Rating V DC:26V; Voltage Rating V AC:20V; Operating Temperature Min:-55°C; Operating Temperature Max:150°C; MSL:-; SVHC:No SVHC (19-Dec-2012); Operating Temperature Range:-55°C to +150°C
Availability: In Stock
Package Type: 0603
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the B72500E0200K060 by EPCOS and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the B72500E0200K060
| Part Name | B72500E0200K060 |
| Manufacturer | EPCOS |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Varistor Voltage (V) | 29.7 → 36.3 (V) |
| Clamping Voltage (V) | 56 (V) |
| Dimensions | 1.6 x 0.8 x 0.9 (mm) |
| Series | CT/B |
| Energy | 0.2 (J) |
| Material | Ceramic |
| Length | 1.6 (mm) |
| Maximum Ac Voltage Rating (V) | 20 (V) |
| Capacitance | 90 (pF) |
| Depth | 0.8 (mm) |
| Maximum Surge Current (A) | 30 (A) |
| Maximum Dc Voltage Rating (V) | 26 (V) |
| Clamping Current (A) | 1 (A) |
| Package/Case | 0603 (1608M) |
