CRM2512-JW-104ELF
Thick Film High Pwr Smnt Resistor 2512 Case 100kOhm +/-5% 2W +/-200ppm/degC | Bourns CRM2512-JW-104ELF
Availability: In Stock
Package Type: 6331
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the CRM2512-JW-104ELF by Bourns and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the CRM2512-JW-104ELF
| Part Name | CRM2512-JW-104ELF |
| Manufacturer | Bourns |
| Category | Electronic Components |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Series | CRM |
| Resistance | 100 (kΩ) |
| Temperature Coefficient | ±200 (ppm/°C) |
| Tolerance | ±5 (%) |
| Technology | Thick Film |
| Minimum Operating Temperature | -55 (°C) |
| Power Rating | 2 (W) |
| Maximum Operating Temperature | +155 (°C) |
| Package/Case | 2512 (6432M) |
