CX70M-24P2
USB-C (USB TYPE-C) USB 3.2 Gen 2 (USB 3.1 Gen 2, Superspeed + (USB 3.1)) Receptacle Connector 24 Position Surface Mount, Right Angle
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the CX70M-24P2 by Hirose and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the CX70M-24P2
| Part Name | CX70M-24P2 |
| Manufacturer | Hirose Electric |
| Type | Receptacle |
| RoHS | True |
| Product Link | https://www.hirose.com/product/p/CL0480-0329-0-00?lang=en |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Usb Version | 3.1 |
| Mounting Type | Surface Mount |
| Voltage Rating (V) | 20.0 V |
| Gender | Female |
| Body Orientation | Right Angle |
| Termination Method | Solder |
| Number Of Ports | 1 |
| Minimum Operating Temperature | -30.0 (°C) |
| Series | CX70M |
| Maximum Operating Temperature | +85 (°C) |
| Usb Type | C |
