DF13-6S-1.25C
6 Rectangular Connectors - Housings Receptacle Beige 0.049" (1.25mm)
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the DF13-6S-1.25C by Hirose and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the DF13-6S-1.25C
| Part Name | DF13-6S-1.25C |
| Manufacturer | Hirose Electric |
| Type | Socket |
| RoHS | True |
| Product Link | https://www.hirose.com/product/p/CL0536-0005-5-00?lang=en |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Mounting Type | Cable Mount |
| Series | DF13 |
| Body Orientation | Straight |
| Distrelec Product Id | 30409514 |
| Length | 9.15 (mm) |
| Housing Material | Polyamide |
| Width | 2.3 (mm) |
| Gender | Male |
| Number Of Rows | 1 |
| Pitch | 1.25 (mm) |
| For Use With | Miniature Crimping Connector |
| Number Of Contacts | 6 |
