ECASD40J107M015K00

Name: ECASD40J107M015K00
Brand: Murata

100 µF 6.3 V Aluminum - Polymer Capacitors 2917 (7343 Metric) 15mOhm 1000 Hrs @ 105°C

Availability: Out of Stock

Package Type: 2917

CAD Models: Symbol, Footprint, 3D Model

Check availability

Check availability

Add to Library See Datasheet PDF Pricing Pinout

What is SnapMagic Search?

SnapMagic Search is a free library of symbols & footprints for the ECASD40J107M015K00 by Murata and for millions of electronic components.

Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.

Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.

Symbol and Footprint
3D Model
Alternates

Symbol

No web preview

This Symbol is Available for

This symbol was not created by SnapMagic Search, please be cautious when using it in your design

Downloaded times

Footprint

No web preview

This Footprint is Available for

This footprint was not created by SnapMagic Search, please be cautious when using it in your design

Downloaded times

3D Model

Preview not available

Note: If you're using IE or Edge, right-click and choose "Save as" to download.

Relevant part with 2D models

Download Part

Verification

Issues

Specs

Pricing

No issues have been reported for the ECASD40J107M015K00

If you experienced any issues with the symbol or footprint, please report it.

New Issue

Specifications for the ECASD40J107M015K00

Part Name	ECASD40J107M015K00
Manufacturer	Murata
Category	Aluminium Capacitors
Sample Link	https://my.murata.com/en/web/samplerequest/cart-requesthistory?pno=ECASD40J107M015K00
Simsurfing Link	https://ds.murata.co.jp/simsurfing/gateway.html?partnumbers=%5B%22ECASD40J107M015K00%22%5D&lcid=en-us&graphop=mainall&focuspartnumberonlist=true&rgear=ytgvkjg
RoHS	True
Product Link	https://www.murata.com/products/productdetail.aspx?partno=ECASD40J107M015K00
Formats Available for Symbols and Footprints	Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus
Datasheet	See Datasheet PDF
Ripple Current (A)	2 (A)
Minimum Operating Temperature	-40 (°C)
Mounting Type	Surface Mount
Tolerance	±20 (%)
Series	ECAS
Length	7.3 (mm)
Equivalent Series Resistance	15 (mΩ)
Height	1.9 (mm)
Capacitance	100 (µF)
Depth	4.3 (mm)
Technology	Polymer
Dissipation Factor	0.06 (%)
Leakage Current (A)	63 μA
Dimensions	7.3 x 4.3 x 1.9 (mm)
Maximum Operating Temperature	+105 (°C)
Polarised	Polar
Voltage (V)	6.3 (V dc)
