EEUFM1C471L
Cap Aluminum Lytic 470uF 16V 20% (8 X 15mm) Radial 3.5mm 1240mA 3000h 105? Bulk
Availability: In Stock
Package Type: RADIAL-2
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the EEUFM1C471L by Panasonic and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the EEUFM1C471L
| Part Name | EEUFM1C471L |
| Manufacturer | Panasonic |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Diameter | 8 (mm) |
| Ripple Current (A) | 1.24 (A) |
| Dimensions | 8 (Dia.) x 15 (mm) |
| Mounting Type | Radial, Through Hole |
| Series | FM-A |
| Height | 15 (mm) |
| Capacitance | 470 (µF) |
| Voltage (V) | 16 (V dc) |
| Minimum Operating Temperature | -40 (°C) |
| Lifetime | 3000 (h) |
| Lead Pitch | 3.5 (mm) |
| Maximum Operating Temperature | +105 (°C) |
| Tolerance | ±20 (%) |
| Polarised | Polar |
| Technology | Aluminium Electrolytic |
Inventory for the EEUFM1C471L by Panasonic from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
8,318
|
|
Visit Site | |
| Avnet America |
|
|
Visit Site | |
| Conrad |
2,450
|
|
Visit Site | |
| Farnell UK |
17,711
|
|
Visit Site | |
| Mouser |
|
|
Visit Site | |
| Newark |
12,586
|
|
Visit Site | |
| RS UK |
1,890
|
5 x $0.93
|
Visit Site | |
| Verical |
12,586
|
|
Visit Site | |
| element14 Singapore |
17,711
|
|
Visit Site |
No issues have been reported for the EEUFM1C471L
If you experienced any issues with the symbol or footprint, please report it.
