EEUFR1H101B
Cap Aluminum 100uF 50V 20% (8 X 11.5mm) Radial 5mm 870mA 6000 hr 105°C Ammo Pack
Availability: In Stock
Package Type: RADIAL-2
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the EEUFR1H101B by Panasonic and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the EEUFR1H101B
| Part Name | EEUFR1H101B |
| Manufacturer | Panasonic |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Ripple Current (A) | 870 (mA) |
| Leakage Current (A) | 50 μA |
| Technology | Aluminium Electrolytic |
| Capacitance | 100 (µF) |
| Voltage (V) | 50 (V dc) |
| Minimum Operating Temperature | -40 (°C) |
| Lead Pitch | 5 (mm) |
| Maximum Operating Temperature | +105 (°C) |
| Polarised | Polar |
