FYD0H473ZF
0.047F -20 - +80% 220Ohms 5.5 V Electric Double Layer Capacitor FYD | KEMET FYD0H473ZF
Availability: In Stock
Package Type: RADIAL
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the FYD0H473ZF by Yageo and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the FYD0H473ZF
| Part Name | FYD0H473ZF |
| Manufacturer | KEMET |
| Category | Electronic Components |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Diameter | 11.5 (mm) |
| Dimensions | 11.5 (Dia.) x 8.5 (mm) |
| Product Diameter | 11.5 (mm) |
| Tolerance | -20 → +80 (%) |
| Series | Supercap FY |
| Capacitor Family | Electric Double Layer |
| Equivalent Series Resistance | 220 (Ω) |
| Height | 8.5 (mm) |
| Capacitance | 47 (mF) |
| Depth | 8.5 (mm) |
| Voltage (V) | 5.5 (V dc) |
| Minimum Operating Temperature | -25 (°C) |
| Lead Spacing | 5.08 mm |
| Mounting Type | Through Hole |
| Lead Pitch | 5.08 (mm) |
| Maximum Operating Temperature | +70 (°C) |
| Terminal Type | Radial |
