G6DN-1A DC24
G6DN Relay 1 form A 24VDC Coil standard Thru-hole | Omron Electronic Components G6DN-1A DC24
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the G6DN-1A DC24 by Omron and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the G6DN-1A DC24
| Part Name | G6DN-1A DC24 |
| Manufacturer | Omron Electronics |
| Category | Relays |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Coil Power | 110 (mW) |
| Series | G6DN |
| Switching Current (A) | 5 (A) |
| Coil Voltage (V) | 24 (V dc) |
| Contact Configuration | SPST |
| Isolation Coil To Contact | 3 (kV) |
| Number Of Poles | 1 |
| Latching | No |
| Coil Resistance | 5236 (Ω) |
