GBS4D
Bridge, 1-ph, GBS_SIL-1.5-2.3, 200V, 140V, 4A
Availability: In Stock
Package Type: GBS/SIL-1.5-2.3
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the GBS4D by Diotec and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the GBS4D
| Part Name | GBS4D |
| Manufacturer | Diotec Semiconductor |
| Article Housing | GBS_SIL-1.5-2.3 |
| RoHS | RoHS Compliant By Exemption |
| Product Link | https://diotec.com/de/produkt/GBS4D.html |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
