IRM-15-24
Power Supply,AC-DC,24V,0.63A,115-264V In,Encapsulated,Thru-Hole,IRM Series | MEAN WELL IRM-15-24
Availability: In Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the IRM-15-24 by Mean Well and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the IRM-15-24
| Part Name | IRM-15-24 |
| Manufacturer | MEAN WELL |
| Category | Power Products |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Outputs | 1 |
| Maximum Temperature | +70 (°C) |
| Mounting Type | PCB Mount |
| Weight | 59 (g) |
| Efficiency | 83 (%) |
| Minimum Temperature | -30 (°C) |
| Depth | 24 (mm) |
| Input Voltage (V) | 120 → 370 V dc, 85 → 264 V ac |
| Width | 27.2 (mm) |
| Length | 52.4 (mm) |
| Output Voltage (V) | 24 (V dc) |
| Package Type | Encapsulated |
| Power Rating | 15 (W) |
| Output Current (A) | 630 (mA) |
Inventory for the IRM-15-24 by Mean Well from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
| Avnet America |
|
|
Visit Site | |
| Chip One Stop |
80
|
|
Visit Site | |
| Conrad |
6
|
|
Visit Site | |
| Farnell UK |
25
|
|
Visit Site | |
| Newark |
25
|
1 x $12.71
|
Visit Site | |
| RS UK |
1,071
|
1 x $9.25
|
Visit Site | |
| Sager |
304
|
|
Visit Site | |
| Schukat Electronic |
5,166
|
|
Visit Site | |
| TME |
801
|
|
Visit Site | |
| TRC Electronics |
|
|
Visit Site | |
| TTI Europe |
450
|
|
Visit Site | |
| element14 Singapore |
25
|
|
Visit Site |
No issues have been reported for the IRM-15-24
If you experienced any issues with the symbol or footprint, please report it.
