IT245
1:1 Through Hole Telecom Transformer, 8mH | Schaffner IT245
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the IT245 by Schaffner and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the IT245
| Part Name | IT245 |
| Manufacturer | Schaffner EMC |
| Category | Power Products |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Temperature | +70 (°C) |
| Dimensions | 16.7 x 17.6 x 11.3 (mm) |
| Mounting Type | Through Hole |
| Minimum Temperature | -25 (°C) |
| Depth | 11.3 (mm) |
| Width | 17.6 (mm) |
| Length | 16.7 (mm) |
| Turns Ratio | 1:1 |
| Primary Voltage Rating (V) | 750 (V) |
| Primary Inductance | 8 (mH) |
