KMD40-1212
AC/DC Power Modules
Availability: Out of Stock
Package Type: DIP-7
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the KMD40-1212 by TDK-Lambda and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the KMD40-1212
| Part Name | KMD40-1212 |
| Manufacturer | TDK-Lambda |
| Life Cycle Status | Not Recommended for New Designs |
| RoHS | True |
| Product Link | https://product.tdk.com/en/search/power/switching-power/ac-dc-converter/info?part_no=KMD40-1212 |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Outputs | 2 |
| Maximum Temperature | +70 (°C) |
| Mounting Type | PCB Mount |
| Weight | 280 (g) |
| Minimum Temperature | -25 (°C) |
| Length | 89 (mm) |
| Input Voltage (V) | 100 → 375 V dc, 90 → 264 V ac |
| Width | 63.5 (mm) |
| Depth | 27 (mm) |
| Output Voltage (V) | ±12 (V dc) |
| Package Type | Encapsulated |
| Power Rating | 40 (W) |
| Output Current (A) | 1.66 (A) |
| Medical Approved | Yes |
