LBP-602DK2
Display Modules - LED Character and Numeric Orange 7-Segment 2 Character Common Cathode 1.9V 10mA 0.748" H x 0.984" W x 0.315" D (19.00mm x 25.00mm x 8.00mm) 18-DIP (0.600", 15.24mm)
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the LBP-602DK2 by Rohm and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the LBP-602DK2
| Part Name | LBP-602DK2 |
| Manufacturer | Rohm |
| RoHS | True |
| Life Cycle Status | Not Recommended for New Designs |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Dominant Wavelength | 605 nm |
| Number Of Segments | 7 |
| For Use With | General Electronic Equipments |
| Forward Current (A) | 20 (mA) |
| Common Connection | Cathode |
| Forward Voltage (V) | 2.6 V |
| External Depth | 19 (mm) |
| Character Width | 8 (mm) |
| Luminous Intensity | 250 mcd |
| Maximum Operating Temperature | +75 (°C) |
| Operating Temperature Range | -25 → +75 (°C) |
| Character Height | 14.3 (mm) |
| Led Colour S | Orange |
| External Dimensions | 25 x 19 x 8 (mm) |
| Display Type | LED |
| Colour Of Face | Black |
| Mounting Type | Through Hole |
| Number Of Characters | 2 |
| Series | LBP-602K2 |
| Power Dissipation | 896 (mW) |
| Minimum Operating Temperature | -25 (°C) |
| Decimal Orientation | Right Side |
| External Height | 8 (mm) |
| External Width | 25 (mm) |
Inventory for the LBP-602DK2 by Rohm from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
160
|
|
Visit Site | |
|
★ Featured
|
333
|
N/A | Visit Site | |
| CoreStaff |
163
|
|
Visit Site | |
| RS UK |
56
|
300 x $3.68
|
Visit Site | |
| Verical |
163
|
|
Visit Site |
No issues have been reported for the LBP-602DK2
