LM22672MRE-ADJ/NOPB
SIMPLE SWITCHER® 4.5V to 42V, 1A Step-Down Voltage Regulator with Adjustable Frequency
Availability: In Stock
Package Type: HSOIC-8
CAD Models: Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the LM22672MRE-ADJ/NOPB by Texas Instruments and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
The 2D model for this
part is not available.
The Exact Symbol for this part is not available.
BuildFootprint

No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
Verification | Issues | Specs | Pricing |
Specifications for the LM22672MRE-ADJ/NOPB
Part Name | LM22672MRE-ADJ/NOPB |
Manufacturer | Texas Instruments |
MOQ | 1 |
Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
Datasheet | See Datasheet PDF |
Number Of Outputs | 1 |
Dimensions | 4.93 x 3.94 x 1.47 (mm) |
Mounting Type | Surface Mount |
Width | 3.94 (mm) |
Maximum Operating Temperature | +125 °C |
Output Type | Adjustable |
Maximum Switching Frequency | 1000 kHz |
Switching Regulator | Yes |
Efficiency | 90 (%) |
Length | 4.93 (mm) |
Package Type | PSOP |
Regulator Function | Buck Controller, Inverting |
Minimum Operating Temperature | -40 °C |
Minimum Output Voltage (V) | 1.258 V |
Height | 1.47 (mm) |
Maximum Output Current (A) | 1 (A) |
Pin Count | 8 |
Maximum Input Voltage (V) | 42 V |
Minimum Input Voltage (V) | 4.5 V |
Inventory for the LM22672MRE-ADJ/NOPB by Texas Instruments from major distributors.
Supplier | Quantity | Price | Purchase | |
---|---|---|---|---|
Texas Instruments |
4,520
|
|
Visit Site |
No issues have been reported for the LM22672MRE-ADJ/NOPB
If you experienced any issues with the symbol or footprint, please report it.
