LTO150F47R00JTE3
RES, 47R, 5%, 150W, TO-247, THICK FILM; Resistance:47ohm; Product Range:LTO 150 Series; Power Rating:150W; Resistance Tolerance:± 5%; Resistor Case Style:TO-247; Voltage Rating:500V; Resistor Element Material:Thick Film; Temperature Coefficient:± 200ppm/°C; Automotive Qualification Standard:AEC-Q200; SVHC:No SVHC (15-Jan-2018)
Availability: In Stock
Package Type: TO-247-2
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the LTO150F47R00JTE3 by Vishay and for millions of electronic components.
