MCP601
General Purpose Amplifier 1 Circuit Rail-to-Rail SOT-23-5
Availability: Out of Stock
Package Type: SOT-23
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the MCP601 by Microchip and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the MCP601
| Part Name | MCP601 |
| Manufacturer | Microchip |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Typical Voltage Gain (V) | 115 dB |
| Typical Input Voltage Noise Density (V) | 29 (nV/√Hz) |
| Dimensions | 3.1 x 1.8 x 1.3 (mm) |
| Mounting Type | Surface Mount |
| Typical Slew Rate | 2.3 (V/µs) |
| Power Supply Type | Single |
| Number Of Channels Per Chip | 1 |
| Rail To Rail | Rail to Rail Output |
| Typical Gain Bandwidth Product | 2.8 (MHz) |
| Typical Single Supply Voltage (V) | 3 V, 5 V |
| Width | 1.8 (mm) |
| Length | 3.1 (mm) |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40 °C |
| Amplifier Type | General Purpose |
| Height | 1.3 (mm) |
| Maximum Operating Temperature | +85 °C |
| Pin Count | 5 |
