MPM-20-5
Power Supply; AC-DC; Encapsulated; Medical; 20W; 5V@4A; 80-264V In | MEAN WELL MPM-20-5
Availability: Out of Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the MPM-20-5 by Mean Well and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the MPM-20-5
| Part Name | MPM-20-5 |
| Manufacturer | MEAN WELL |
| Category | Power Products |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Outputs | 1 |
| Maximum Temperature | +85 (°C) |
| Mounting Type | PCB Mount |
| Weight | 56 (g) |
| Minimum Temperature | -35 (°C) |
| Length | 52.4 (mm) |
| Input Voltage (V) | 80 → 264 (V ac) |
| Width | 27.2 (mm) |
| Depth | 24 (mm) |
| Output Voltage (V) | 5 (V dc) |
| Package Type | Encapsulated |
| Distrelec Product Id | 30386034 |
| Power Rating | 20 (W) |
| Output Current (A) | 4 (A) |
| Medical Approved | Yes |
No issues have been reported for the MPM-20-5
