PKGS-00GXP1-R
Vibration, Piezo Film Shock Sensor 0 ~ 50G 0.840pC/G Surface Mount
Availability: Out of Stock
Package Type: SMD-2
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the PKGS-00GXP1-R by Murata Electronics North America and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the PKGS-00GXP1-R
| Part Name | PKGS-00GXP1-R |
| Manufacturer | Murata Electronics |
| Product Link | https://www.murata.com/en-us/products/productdetail?partno=PKGS-00GXP1-R |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Shock Vibration | 29400 (m/s²) |
| Dimensions | 3.8 x 2 x 1.05 mm |
| Length | 3.8 (mm) |
| Width | 2 (mm) |
| Depth | 1.05 (mm) |
| Minimum Operating Temperature | -40 (°C) |
| Maximum Operating Temperature | +80 (°C) |
No issues have been reported for the PKGS-00GXP1-R
If you experienced any issues with this part, please report it.
