RC2512JK-7W1RL
RESISTOR, 2512 1R 2W 5%; Resistance:1ohm; Resistance Tolerance:± 5%; Power Rating:2W; Voltage Rating:200V; Temperature Coefficient:± 200ppm/°C; Resistor Element Material:Thick Film; Resistor Case Style:2512; Resistor Mounting:SMD; SVHC:No SVHC (20-Jun-2011); External Depth:0.55mm; External Length / Height:6.35mm; External Width:3.1mm; No. of Pins:2; Operating Temperature Max:185°C; Operating Temperature Min:-55°C; Operating Temperature Range:-55°C to +185°C; Package / Case:2512; Series:RC2512; Temperature Coeff. +:200ppm/°C; Temperature Coeff. -:200ppm/°C; Termination Type:SMD; Tolerance +:5%; Tolerance -:5%; Voltage Rating V DC:200V
Availability: In Stock
Package Type: 6331
CAD Models: Symbol, Footprint, 3D Model
