RP30-2412DEW
Recom Iso DC-DC Converter,Vin 10to40VDC,Vout +/-12VDC,I/O isolation 1.6kV | RECOM Power Inc. RP30-2412DEW
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the RP30-2412DEW by Recom Power and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the RP30-2412DEW
| Part Name | RP30-2412DEW |
| Manufacturer | Recom Power |
| Category | Power Products |
| Number of Outputs | 2.0 |
| Isolation Voltage (V) | 1600.0 |
| Case Package | 2"x1.6" |
| Series | RP30-EW |
| Short Circuit Protection | True |
| Packaging Type | Tube |
| Lead Free Status | True |
| Input Voltage (V) | [10.0, 40.0] |
| Product Link | https://recom-power.com/en/products/dc-dc-converters/rec-p-RP30-2412DEW.html |
| Power Rating | 30.0 |
| Output Voltage (V) | [12.0, 12.0] |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Depth | 10.2 (mm) |
| Number Of Outputs | 2 |
| Maximum Temperature | +85 (°C) |
| Isolation Voltage (V) | 1.6 (kV dc) |
| Output Current (A) | ±1.25 (A) |
| Mounting Type | Through Hole |
| Package | 1.6 x 2 in |
| Series | RP30-EW |
| Input Voltage Range (V) | 10 → 40 V dc |
| Isolated | Yes |
| Length | 40.6 (mm) |
| Load Regulation | ±0.1 (%) |
| Minimum Temperature | -40 (°C) |
| Input Voltage Nominal (V) | 24 V dc |
| Power Rating | 30 (W) |
| Output Voltage (V) | ±12 (V dc) |
No issues have been reported for the RP30-2412DEW
