RSL1PRBU
Relay w/Socket,24VDC Ctrl,277V Switching,6A,Spring Clamp,PCB Pin,Socket Mnt | Schneider Electric RSL1PRBU
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the RSL1PRBU by Schneider Electric and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the RSL1PRBU
| Part Name | RSL1PRBU |
| Manufacturer | Schneider Electric |
| Category | Relays |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Better World Verification | Green Premium |
| Better World Product | Yes |
| Operating Temperature Range | -40 °C → +55 (°C) |
| Series | Harmony Relay RSL |
| Coil Voltage (V) | 24 (V ac/dc) |
| Number Of Poles | 1 |
| Life | 10000000 cycles |
| Contact Configuration | SPDT |
| Depth | 78.7 (mm) |
| Relay Switching Classification | Slimline Relay |
| Length | 6.2 (mm) |
| Minimum Operating Temperature | -40 (°C) |
| Special Features | LED Indicator, Slim Relay |
| Height | 103 (mm) |
| Maximum Operating Temperature | +55 (°C) |
| Terminal Type | Cage Clamp |
| Contact Material | Silver Alloy |
Inventory for the RSL1PRBU by Schneider Electric from major distributors.
| Supplier | Quantity | Price | Purchase | |
|---|---|---|---|---|
|
★ Featured
|
|
1 x $19.15
|
Visit Site | |
|
★ Featured
|
142
|
|
Visit Site | |
| Buerklin |
10
|
|
Visit Site | |
| Conrad |
2
|
|
Visit Site | |
| RS UK |
95
|
1 x $31.09
|
Visit Site | |
| Standard Electric Supply |
203
|
1 x $21.93
|
Visit Site |
No issues have been reported for the RSL1PRBU
If you experienced any issues with this part, please report it.
