RSP-500-48
Power Supply,AC-DC,48V,10.5A,100-264V In,Enclosed,Panel Mount,PFC,RSP-500 Series | MEAN WELL RSP-500-48
Availability: In Stock
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the RSP-500-48 by Mean Well and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the RSP-500-48
| Part Name | RSP-500-48 |
| Manufacturer | Mean Well |
| Category | Power Products |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Number Of Outputs | 1 |
| Maximum Temperature | +70 (°C) |
| Mounting Type | Chassis Mount |
| Weight | 1.3 (kg) |
| Efficiency | 90.5 (%) |
| Minimum Temperature | -30 (°C) |
| Distrelec Product Id | 30015946 |
| Depth | 40.5 (mm) |
| Width | 127 (mm) |
| Length | 230 (mm) |
| Input Voltage (V) | 120 → 370 V dc, 85 → 264 V ac |
| Package Type | Enclosed |
| Output Voltage (V) | 48 (V dc) |
| Power Rating | 504 (W) |
| Output Current (A) | 10.5 (A) |
