RV1206JR-073M3L
RESISTOR, 1206 HIGH VOLTAGE 5% 3M3; Resistance:3.3Mohm; Resistance Tolerance:± 5%; Power Rating:0.25W; Voltage Rating:500V; Series:RV; Temperature Coefficient:± 200ppm/°C; Resistor Element Type:Thick Film; Resistor Case Style:1206; No. of Pins:2; SVHC:No SVHC; Case Style:1206; External Length / Height:3.1mm; Temperature Coeff. +:200ppm/°C; Temperature Coeff. -:200ppm/°C; Tolerance, +:5%; Tolerance, -:5%; Voltage Rating DC:500V; External Depth:0.55mm; External Width:1.60mm; Max Operating Temperature:155°C; Min Temperature Operating:-55°C; Operating Temperature Range:-55°C to +155°C; Termination Type:SMD
