SC0683
The Raspberry Pi Compute Module 4 Rev 5 CM4004000 lite is a high-performance embedded computer ideal for a variety of applications. Featuring a 1.5GHz quad-core ARM Cortex-A72 processor and 4GB of RAM, it delivers significant processing power and efficient multitasking capabilities. Connectivity options include GbE Ethernet and USB 2.0, along with expansion sites for I2C, SPI, and UART interfaces. With 28 digital I/O lines and video outputs such as CSI, DPI, DSI, and HDMI, this SBC offers many different interfacing options for all of your projects.
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the SC0683 by Raspberry Pi and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
