SC0692
The Raspberry Pi Compute Module 4 CM4101008 single board computer features a powerful 1.5GHz quad-core ARM Cortex-A72 processor and 1GB of RAM, making it ideal for a variety of embedded computing applications. With 28 digital I/O lines, GbE Ethernet, and multiple expansion interfaces including I2C, SPI, and UART, this SBC offers varied connectivity options. It supports video outputs through CSI, DPI, DSI, and HDMI. The compact dimensions of 2.170" x 1.570" (55.00mm x 40.00mm) and an operating temperature range of -20°C to 75°C ensure flexibility and reliability in various environments.
Availability: Out of Stock
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the SC0692 by Raspberry Pi and for millions of electronic components.
