SI4461C2AGM by Silicon Labs

SI4461C2AGM

RF TRANSCEIVER, 0.142-1.05GHZ, HQFN-20; Frequency Min:142MHz; Frequency Max:1.05GHz; RF / IF Modulation:4FSK, 4GFSK, FSK, GFSK, MSK, GMSK, OOK; Data Rate:1Mbps; Receiving Current:13mA; RF IC Case Style:HQFN; No. of Pins:20Pins; Supply Voltage Min:1.8V; Supply Voltage Max:3.8V; Transmitting Current:43mA; Output Power (dBm):16dBm; Sensitivity dBm:-129dBm; RF Transceiver Applications:IEEE 802.11g & WMBus, Wireless Sensor Networks, Home Automation, Industrial Process Control; Operating Temperature Min:-40°C; Operating Temperature Max:85°C; Product Range:-; RoHS Phthalates Compliant:To Be Advised; MSL:MSL 1 - Unlimited

Availability: In Stock

CAD Models: Symbol and Footprint

Buy Now from Arrow

0 in stock at $ USD

Check availability y
Buy Now from RS Components
Check availability y
Buy Now from Win Source
Check availability y
Buy Now from Mouser

Starting from:

Check availability y
Add to Library See Datasheet PDF Pricing Pinout
