SPX1117M3-L-3-3/TR
Linear Voltage Regulator IC Positive Fixed 1 Output 800mA SOT-223-3
Availability: In Stock
Package Type: SOT-223
CAD Models: Symbol, Footprint, 3D Model
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the SPX1117M3-L-3-3/TR by MaxLinear and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the SPX1117M3-L-3-3/TR
| Part Name | SPX1117M3-L-3-3/TR |
| Manufacturer | MaxLinear |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Polarity | Positive |
| Dimensions | 6.5 x 3.5 x 1.6 (mm) |
| Regulator Type | Low Dropout Voltage |
| Width | 3.5 (mm) |
| Reference Voltage (V) | 1.262 (V) |
| Accuracy | ±1 (%) |
| Number Of Outputs | 1 |
| Load Regulation | 0.2 % |
| Output Type | Fixed |
| Package Type | SOT-223 |
| Maximum Operating Temperature | +125 °C |
| Quiescent Current (A) | 5 (mA) |
| Line Regulation | 0.1 % |
| Length | 6.5 (mm) |
| Pin Count | 3+Tab |
| Mounting Type | Surface Mount |
| Height | 1.6 (mm) |
| Output Voltage (V) | 3.3 V |
| Minimum Operating Temperature | -40 °C |
| Maximum Output Current (A) | 800 (mA) |
| Maximum Input Voltage (V) | 15 V |
| Minimum Input Voltage (V) | 2.6 V |
