SRDA05-6.TBT
20V Clamp 25A (8/20µs) Ipp Tvs Diode Surface Mount 8-SO
Availability: Out of Stock
Package Type: SOIC-8
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the SRDA05-6.TBT by Semtech and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
2D Model
The 2D model for this
part is not available
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the SRDA05-6.TBT
| Part Name | SRDA05-6.TBT |
| Manufacturer | Semtech Corporation |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Peak Pulse Current (A) | 25 (A) |
| Maximum Reverse Stand-Off Voltage (V) | 5 (V) |
| Dimensions | 5 x 4 x 1.5 (mm) |
| Mounting Type | Surface Mount |
| Direction Type | Uni-Directional |
| Maximum Operating Temperature | +125 °C |
| Maximum Reverse Leakage Current (A) | 10 (µA) |
| Esd Protection | Yes |
| Height | 1.5 (mm) |
| Width | 4 (mm) |
| Length | 5 (mm) |
| Package Type | SOIC |
| Number Of Elements Per Chip | 1 |
| Minimum Operating Temperature | -55 °C |
| Maximum Clamping Voltage (V) | 20 (V) |
| Diode Configuration | Single |
| Pin Count | 8 |
| Peak Pulse Power Dissipation | 500 (W) |
No issues have been reported for the SRDA05-6.TBT
