SRP1265A-2R2M
Inductor,Shielded Power,AEC-Q200,2.2uH 20% SMT 1265 | Bourns SRP1265A-2R2M
Availability: In Stock
Package Type: NONSTANDARD
CAD Models: Symbol and Footprint
What is SnapMagic Search?
SnapMagic Search is a free library of symbols & footprints for the SRP1265A-2R2M by Bourns and for millions of electronic components.
Compatible with Eagle, Altium, Cadence OrCad & Allegro, KiCad, & more.
Discover parts from Texas Instruments, Microchip, TE Connectivity, Vishay & more.
- Symbol and Footprint
- 3D Model
- Alternates
Symbol
No web preview
This Symbol is Available for
Footprint
No web preview
This Footprint is Available for
3D Model
Preview not available
Note: If you're using IE or Edge, right-click and choose "Save as" to download.
Get this 3D Model in 1 business day!
More
| Verification | Issues | Specs | Pricing |
Specifications for the SRP1265A-2R2M
| Part Name | SRP1265A-2R2M |
| Manufacturer | Bourns |
| Category | Electronic Components |
| RoHS | True |
| Formats Available for Symbols and Footprints |
Altium, Eagle, KiCAD, Cadence OrCad/Allegro, PADS, DxDesigner, PCB123, Pulsonix, Proteus |
| Datasheet | See Datasheet PDF |
| Maximum Dc Resistance | 4.2 (Ω) |
| Inductor Construction | Shielded |
| Dimensions | 13.5 x 12.5 x 6.2 (mm) |
| Inductance | 2.2 μH |
| Shielded | Yes |
| Series | SRP1265A |
| Minimum Quality Factor | 20 |
| Depth | 12.5 (mm) |
| Height | 6.2 (mm) |
| Package Case | 1265 |
| Length | 13.5 (mm) |
| Core Material | Carbonyl Powder |
| Minimum Operating Temperature | -40 (°C) |
| Maximum Self Resonant Frequency | 23 (MHz) |
| Maximum Dc Current (A) | 22 (A) |
| Maximum Operating Temperature | +150 (°C) |
| Tolerance | ±20 (%) |
| Automotive Standard | AEC-Q200 |
